80 Datasheet

Intel

Celeron

Processor up to 1.10 GHz

Table 47. Package Dimensions (PPGA Package)

Millimeters Inches

Symbol Min Max Notes Min Max Notes

A 1.83 2.23 0.072 0.088

A1 1.00 0.039

A2 2.72 3.33 0.107 0.131

B 0.40 0.51 0.016 0.020

D 49.43 49.63 1.946 1.954

D1 45.59 45.85 1.795 1.805

D2 25.15 25.65 0.099 1.010

e1 2.29 2.79 0.090 0.110

L 3.05 3.30 0.120 0.130

N 370 Lead Count 370 Lead Count

S1 1.52 2.54 0.060 0.100

Table 48. Information Summary (PPGA Package)

Package Type Total Pins Pin Array Package Size

Plastic Staggered Pin Grid Array (PPGA) 370 37 x 37

1.95" x 1.95"

4.95 cm x 4.95 cm
