128 Datasheet

Intel

Celeron

Processor up to 1.10 GHz

Table 62. Input/Output Signals (Single Driver)

Name Active Level Clock Signal Group Qualified

BSEL[1:0] Low Asynch Power/Other Always

BP[3:2] Low BCLK AGTL+ I/O Always

BR0# Low BCLK AGTL+I/O Always

A[31:3]# Low BCLK AGTL+ I/O ADS#, ADS#+1

ADS# Low BCLK AGTL+ I/O Always

BPM[1:0]# Low BCLK AGTL+ I/O Always

D[63:0]# Low BCLK AGTL+ I/O DRDY#

DBSY# Low BCLK AGTL+ I/O Always

DRDY# Low BCLK AGTL+ I/O Always

LOCK# Low BCLK AGTL+ I/O Always

REQ[4:0]# Low BCLK AGTL+ I/O ADS#, ADS#+1

Table 63. Input/Output Signals (Multiple Driver)

Name Active Level Clock Signal Group Qualified

BNR# Low BCLK AGTL+ I/O Always

HIT# Low BCLK AGTL+ I/O Always

HITM# Low BCLK AGTL+ I/O Always

PICD[1:0] High PICCLK APIC I/O Always
