SRPL8 Server System Product Guide 37

The rest of this section lists the features that display onscreen after you press <F2> to enter Setup.

Not all of the option choices are described, because (1) a few are not user-selectable but are

displayed for your information, and (2) many of the choices are relatively self-explanatory.

Press To

F1 Get help about an item.

ESC Go back to a previous item.

↑ Select the previous value in a menu option list.

↓ Select the next value in a menu option list.

← → Select a major menu.

- Change the value of the current menu item to the previous value.

+ Change the value of the current menu item to the next value.

Enter Activate submenus, select feature options, and change feature values.

F9 Display the following message:

Setup Confirmation

Load default configuration now?

[Yes] [No]

The [Yes] button will be highlighted. If you press <Enter>, all Setup fields return to their

default values. If you press <ESC> or select No, the server returns to the configuration it

had before you pressed <F9>, without affecting any existing field values.

F10 Display the following message:

Setup Confirmation

Save configuration changes and exit now?

[Yes] [No]

The [Yes] button will be highlighted. If you press <Enter>, all current Setup values are

saved, and the system is reset. If you press <ESC> or select No, the server returns to

the configuration it had before you pressed <F10>, without affecting any existing values.
