SRPL8 Server System Product Guide 173
OM10940
AB
C
D
E
F
H
G
I
J
Figure 56. I/O Carrier Layout
A. IDE and diskette connectors
B. PHP LED/switch connector
C. USB connector
D. I/O riser board connector
E. PCI add-in board slots (ten)
F. Lithium battery
G. Configuration switch SW4G1
H. Server management feature connector (SFC)
I. Grand connector (connects to midplane)
J. SCSI A and B connectors
