PENTIUM® III XEON™ PROCESSOR AT 600 MHz to 1 GHz with 256KB L2 Cache

BOXED PROCESSOR SPECIFICATIONS

1.5

4.24

Figure 38. Side View Space Recommendation for the Auxiliary Fan

Figure 39. Front View Space Recommendation for the Auxiliary Fan

9.3.2.2 Fan power recommendations for auxiliary fan

To facilitate power to the auxiliary fan and provide fan monitoring, a fan-sense capable power header may be

provided on the baseboard near every processor that may need an auxiliary fan. Although the boxed

processor does not ship with an auxiliary fan, it is highly recommended that a power header be provided. It is
