BIOS

Page 4-17

Current System/CPU Temperature

Displays the current system/CPU temperature.

Thermo Stick Temperature

Displays the current thermo Stick temperature.

Current CPU/Chassis/Power FAN Speed

Displays the current speed of the CPU, chassis, and power fan speed in RPMs.

VDimm

The voltage level of the DRAM.

Chipset Voltage

The voltage level of chipset.

Vcore

The voltage level of the CPU (Vcore).

+12V, VCC, 5VSB, 3VSB

The voltage level of the switching power supply.

VBAT

The voltage level of the battery.

ACPI Shutdown Temperature

This is the temperature that the computer will turn off the power to combat the

effects of an overheating system. (requires ACPI to be enabled in Power Manage-

ment BIOS and ACPI compliant operating system.) The default is Disabled.

Options available are 60

C/140

F to 95

C/203

F in increments of 5
