Specification

Page 2-3

BIOS

 Flash EEPROM with Award Plug&Play BIOS

 Support ACPI S3 (Suspend To RAM) mode in ACPI compliant O/S

 Support EZ Boot for fast bootable device selection

 Support Magic Health for system hardware status report during system

boot-up

Peripheral Interfaces

) At Rear Panel

 PS/2 keyboard and mouse ports

 One Parallel (printer) port

 One S/PDIF-Out Coaxial jack

 One Serial port

 One RJ45 LAN connector

 Four USB2.0 ports

 Six Audio jacks

) Onboard connector and pin-header

 One floppy drive connector

 One ATA-100 IDE connector

 Four extra USB2.0 ports

 One CD-IN connector

 One IR connector

 Four S-ATA II connectors

 Three Fan connectors

Front Panel Controller

 Supports Reset & Soft-Off switches

 Supports HDD & Power LEDs

 Supports PC speaker

 Supports Front Panel Audio connector
