Intel® Server System SR1640TH Technical Product Specification Intel order number: E94847-001 Revision 1.0March 2010Enterprise Platforms a

List of Tables Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 x Table 46. CMOS Clear (J1G2, J9J1) ...

Intel® Server System SR1640TH TPS Environmental and Regulatory Specification Revision 1.0 Intel order number: E94847-001 88 8.6 Electromagnetic C

Environmental and Regulatory Specification Intel® Server System SR1640TH TPS Revision 1.0 89 Intel order number: E94847-001 8.6.3 Europe (CE Declar

Intel® Server System SR1640TH TPS Environmental and Regulatory Specification Revision 1.0 Intel order number: E94847-001 90 slides. You must also c

Environmental and Regulatory Specification Intel® Server System SR1640TH TPS Revision 1.0 91 Intel order number: E94847-001 8.8 Power Cord Usage G

Intel® Server System SR1640TH TPS Environmental and Regulatory Specification Revision 1.0 Intel order number: E94847-001 92 Compliance Regional Des

Environmental and Regulatory Specification Intel® Server System SR1640TH TPS Revision 1.0 93 Intel order number: E94847-001 Compliance Description

Intel® Server System SR1640TH TPS Appendix A: Integration and Usage Tips Revision 1.0 Intel order number: E94847-001 94 Appendix A: Integration and

Appendix B: Integrated BMC Sensor Tables Intel® Server System SR1640TH TPS Revision 1.0 95 Intel order number: E94847-001 Appendix B: Integrated

Intel® Server System SR1640TH TPS Appendix B: Integrated BMC Sensor Tables Revision 1.0 Intel order number: E94847-001 96  Rearm Sensors The rear

Appendix B: Integrated BMC Sensor Tables Intel® Server System SR1640TH TPS Revision 1.0 97 Intel order number: E94847-001 Sensor Name3 Sensor

Intel® Server System SR1640TH TPS List of Tables Revision 1.0 Intel order number: E94847-001 xi < This page intentionally left blank >

Intel® Server System SR1640TH TPS Appendix B: Integrated BMC Sensor Tables Revision 1.0 Intel order number: E94847-001 98 Sensor Name3 Sens

Appendix C: POST Code LED Decoder Intel® Server System SR1640TH TPS Revision 1.0 99 Intel order number: E94847-001 Appendix C: POST Code LED Deco

Intel® Server System SR1640TH TPS Appendix C: POST Code LED Decoder Revision 1.0 Intel order number: E94847-001 100 Table 82. POST Progress Code L

Appendix C: POST Code LED Decoder Intel® Server System SR1640TH TPS Revision 1.0 101 Intel order number: E94847-001 Diagnostic LED Decoder O = On

Intel® Server System SR1640TH TPS Appendix D: POST Code Errors Revision 1.0 Intel order number: E94847-001 102 Appendix D: POST Code Errors Wheneve

Appendix D: POST Code Errors Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 103 Error Code Error Message Resp

Intel® Server System SR1640TH TPS Appendix D: POST Code Errors Revision 1.0 Intel order number: E94847-001 104 Error Code Error Message Response

Appendix D: POST Code Errors Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 105 Error Code Error Message Resp

Intel® Server System SR1640TH TPS Glossary Revision 1.0 107 Intel order number: E94847-001 Glossary Term Definition ACPI Advanced Configuratio

Glossary Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 108 Term Definition LAN Local Area Network LCD Liquid Cr

Intel® Server System SR1640TH TPS Glossary Revision 1.0 109 Intel order number: E94847-001 Term Definition VRD Voltage Regulator Down Word 16-

Reference Documents Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 110 Reference Documents Refer to the following d

Intel® Server System SR1640TH TPS Introduction Revision 1.0 Intel order number: E94847-001 1 1. Introduction This Technical Product Specificat

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 2 2. Functional Architecture The Intel® Serv

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 Intel order number: E94847-001 3 Feature Description Three 8-pin sy

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 4 2.1 System Views There are 2 trays in SR1

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 Intel order number: E94847-001 5 Figure 3. System trays overview with p

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 6 2.3 System Components A Fixed 3.5 inch H

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 Intel order number: E94847-001 7 2.4 Server Board Overview Intel® Serve

Revision History Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 ii Revision History Date Revision Number Modifica

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 8 Figure 6. Server board S3420TH block diagr

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 Intel order number: E94847-001 9 2.4.2.2 Intel® Core™ i3 Processor The

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 10 memory. Each DDR3 channel in the IMC suppo

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 Intel order number: E94847-001 11 z 0xEB - Memory Test Error: If a DDR3

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 12 feature offered by the Intel® S3420 I/O Hu

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 Intel order number: E94847-001 13 5. The DIMM identifiers on the silksc

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 14 This table defines half of the valid memor

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 Intel order number: E94847-001 15 To get the maximum memory size on RDIM

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 16 2.4.5.2 Serial ATA Support The Intel® 342

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 Intel order number: E94847-001 17 2.4.6 Integrated Baseboard Managemen

Intel® Server System SR1640TH TPS Disclaimers Revision 1.0 Intel order number: E94847-001 iii Disclaimers Information in this document is prov

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 18 ARM926EJ-S16K D & I CacheInterruptCo

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 Intel order number: E94847-001 19 Table 9. Optional RMM3 Advanced Manage

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 20 2.4.8 Network Interface Controller (NIC)

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 21 Intel order number: E94847-001 2.5 Platform Management The platform m

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 22  The Integrated Baseboard Management Con

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 23 Intel order number: E94847-001 2.5.2.2.2 Video Video output from the

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 24 2.5.2.5 Local Directory Authentication Pr

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 25 Intel order number: E94847-001 Error Manager No.

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 26 2.6.3 BIOS Setup utility The BIOS setup u

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 27 Intel order number: E94847-001 Each Setup menu page contains a number

Table of Contents Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 iv Table of Contents 1. Introduction ...

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 28 can select the menus listed here. Some men

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 29 Intel order number: E94847-001 Table 13. Setup Utility – Main Screen F

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 30 Main Advanced Security Server Manageme

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 31 Intel order number: E94847-001 Advanced Processor Configuratio

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 32 Setup Item Options Help Text Comments P

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 33 Intel order number: E94847-001 2.6.5.2.2 Memory Screen The Memory scr

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 34 Setup Item Comments DIMM_ XY Displays th

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 35 Intel order number: E94847-001 Setup Item Options Help Text Comment

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 36 Setup Item Options Help Text Comments L

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 37 Intel order number: E94847-001 Table 19. Setup Utility – PCI Configura

Intel® Server System SR1640TH TPS Table of Contents Revision 1.0 Intel order number: E94847-001 v 3.4.5 Susceptibility Requirements ...

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 38 Table 20. Setup Utility – System Acoustic

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 39 Intel order number: E94847-001 Table 21. Setup Utility – Security Conf

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 40 Main Advanced Security Server Manageme

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 41 Intel order number: E94847-001 Setup Item Options Help Text Comment

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 42 Setup Item Options Help Text Comments A

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 43 Intel order number: E94847-001 Figure 20. Setup Utility – BMC configur

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 44 Setup Item Options Help Text Comments n

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 45 Intel order number: E94847-001 Setup Item Options Help Text Comment

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 46 Table 26. Setup Utility – Add New Boot Opt

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 47 Intel order number: E94847-001 Setup Item Options Help Text Hard Dis

Table of Contents Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 vi 6.1 Control Panel Button...

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 48 Setup Item Options Help Text Floppy Disk

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 49 Intel order number: E94847-001 Setup Item Options Help Text BEV Devi

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 50 2.6.5.10 Exit Screen The Exit screen allo

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 51 Intel order number: E94847-001 2.6.6 Loading BIOS Defaults Different

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 52 Figure 32. Connector locations on server

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 53 Intel order number: E94847-001 2.7.1.1 Power Connectors The main powe

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 54 2.7.1.3 Front Control Panel Connector

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 55 Intel order number: E94847-001 Table 42. SAS 4i connector pin-out (J9J

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 56 2.7.1.8 Power to backplane connectors The

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 57 Intel order number: E94847-001 Figure 34. Jumper locations on board

Intel® Server System SR1640TH TPS List of Figures Revision 1.0 Intel order number: E94847-001 vii List of Figures Figure 1. System Overview...

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 58 2.7.2.1 CMOS Clear (J1G2, J9J1) When ena

Intel® Server System SR1640TH TPS Functional Architecture Revision 1.0 59 Intel order number: E94847-001 LSB MSB 1 1 1 1 Figure 35. Boar

Functional Architecture Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 60 A AC Power Receptacle F Node1: RMM3 Li

Intel® Server System SR1640TH TPS Power Sub-System Revision 1.0 61 Intel order number: E94847-001 3. Power Sub-System The system includes two 4

Power Sub-System Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 62 Note: Signals that can be defined as low true or

Intel® Server System SR1640TH TPS Power Sub-System Revision 1.0 63 Intel order number: E94847-001 3.4.2 Input current The maximum input current

Power Sub-System Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 64 3.4.5.1 Electrostatic Discharge Susceptibility

Intel® Server System SR1640TH TPS Power Sub-System Revision 1.0 65 Intel order number: E94847-001 3.4.8 AC Line Leakage Current The maximum le

Power Sub-System Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 66 Output MIN MAX +12V 2 A 37 A 3.5.2 Remote S

Intel® Server System SR1640TH TPS Power Sub-System Revision 1.0 67 Intel order number: E94847-001 Table 63. Capacitive load Output Min Ma

List of Figures Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 viii Figure 46. Jumper location on Server Board S3420

Power Sub-System Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 68 Table 65. +12V Over-Voltage Protection (OVP) requ

Intel® Server System SR1640TH TPS Power Sub-System Revision 1.0 69 Intel order number: E94847-001 3.7.1 Power supply management controller (PSM

Power Sub-System Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 70 3.8.2 Data Format The data format for current,

Intel® Server System SR1640TH TPS Power Sub-System Revision 1.0 71 Intel order number: E94847-001 Table 69. Product Information Field name Fie

Cooling Sub-System Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 72 4. Cooling Sub-System Several components and co

Intel® Server System SR1640TH TPS Cooling Sub-System Revision 1.0 73 Intel order number: E94847-001 4.2 Three-Fan Module The system tray inclu

Cooling Sub-System Intel® Server System SR1640TH TPS Revision 1.0 Intel order number: E94847-001 74 Figure 41. Air Duct Module assembly process

Hard Disk Drive Support Intel® Server System SR1640TH TPS Revision 1.0 75 Intel order number: E94847-001 5. Hard Disk Drive Support The server syst

Intel® Server System SR1640TH TPS Hard Disk Drive Support Revision 1.0 Intel order number: E94847-001 76 Figure 43. 3.5-inch HDD Assembly Overview

Front Panel Control and Indicators Intel® Server System SR1640TH TPS Revision 1.0 77 Intel order number: E94847-001 6. Front Panel Control and Indi

Intel® Server System SR1640TH TPS List of Tables Revision 1.0 Intel order number: E94847-001 ix List of Tables Table 1. System Feature Set ...

Intel® Server System SR1640TH TPS Front Panel Control and Indicators Revision 1.0 Intel order number: E94847-001 78 Table 71. Front LED Indicator

Front Panel Control and Indicators Intel® Server System SR1640TH TPS Revision 1.0 79 Intel order number: E94847-001 Color State Criticality Descr

Intel® Server System SR1640TH TPS Front Panel Control and Indicators Revision 1.0 Intel order number: E94847-001 80  Controlled by the Chassis Id

Configuration Jumpers Intel® Server System SR1640TH TPS Revision 1.0 81 Intel order number: E94847-001 7. Configuration Jumpers The following chapt

Intel® Server System SR1640TH TPS Configuration Jumpers Revision 1.0 Intel order number: E94847-001 82 7.1 Force IBMC Update (J1A1, J5A1) When per

Configuration Jumpers Intel® Server System SR1640TH TPS Revision 1.0 83 Intel order number: E94847-001 Steps for clearing the CMOS 1. Power down se

Intel® Server System SR1640TH TPS Environmental and Regulatory Specification Revision 1.0 Intel order number: E94847-001 84 8. Environmental and R

Environmental and Regulatory Specification Intel® Server System SR1640TH TPS Revision 1.0 85 Intel order number: E94847-001 WARNING Danger of explo

Intel® Server System SR1640TH TPS Environmental and Regulatory Specification Revision 1.0 Intel order number: E94847-001 86 compliance testing. For

Environmental and Regulatory Specification Intel® Server System SR1640TH TPS Revision 1.0 87 Intel order number: E94847-001 Compliance Regional Desc
