Appendix C: POST Code LED Decoder Intel® Server System SR1640TH TPS

Revision 1.0 101

Intel order number: E94847-001

Diagnostic LED Decoder

O = On, X=Off

Upper Nibble Lower Nibble

MSB LSB

Checkpoint

8h 4h 2h 1h 8h 4h 2h 1h

LED #7 #6 #5 #4 #3 #2 #1 #0

Description

0x99h O X X O X X O O

Detecting the mouse

0x9Ah O X X O X O O X

Detecting the presence of mouse

0x9Bh O X X O X O O O

Enabling the mouse

Fixed Media

0xB0h O X O O X X X X

Resetting fixed media device

0xB1h O X O O X X X O

Disabling fixed media device

0xB2h O X O O X X O X

Detecting presence of a fixed media device (SATA hard drive detection,

etc.)

0xB3h O X O O X X O O

Enabling / configuring a fixed media device

Removable Media

0xB8h O X O O O X X X Resetting removable media device

0xB9h O X O O O X X O Disabling removable media device

0xBAh O X O O O X O X

Detecting presence of a removable media device (SATA CDROM

detection, etc.)

0xBCh O X O O O O X X Enabling / configuring a removable media device

Boot Device Selection (BDS)

0xD0 O O X O X X X X Entered the Boot Device Selection phase (BDS)

0xD1 O O X O X X X O Return to last good boot device

0xD2 O O X O X X O X Setup boot device selection policy

0xD3 O O X O X X O O Connect boot device controller

0xD4 O O X O X O X X Attempt flash update boot mode

0xD5 O O X O X O X O Transfer control to EFI boot

0xD6 O O X O X O O X Trying to boot device selection

0xDF O O X O O O O O Reserved for boot device selection

Pre-EFI Initialization (PEI) Core

0xE0h O O O X X X X X Entered Pre-EFI Initialization phase (PEI)

0xE1h O O O X X X X O Started dispatching early initialization modules (PEIM)

0xE2h O O O X X X O X Initial memory found, configured, and installed correctly

0xE3h O O O X X X O O Transfer control to the DXE Core

Driver eXecution Environment (DXE) Core

0xE4h O O O X X O X X

Entered EFI driver execution phase (DXE)

0xE5h O O O X X O X O

Started dispatching drivers

0xE6h O O O X X O O X

Started connecting drivers

DXE Drivers

0xE7h O O O X O O X O Waiting for user input

0xE8h O O O X O X X X Checking password

0xE9h O O O X O X X O Entering BIOS setup

0xEAh O O O X O O X X Flash Update

0xEEh O O O X O O X X Calling Int 19. One beep unless silent boot is enabled.

0xEFh O O O X O O X O Unrecoverable boot failure

Pre-EFI Initialization Module (PEIM) / Recovery

0x30h X X O O X X X X

Crisis recovery has been initiated because of a user request

0x31h X X O O X X X O

Crisis recovery has been initiated by software (corrupt flash)

0x34h X X O O X O X X

Loading crisis recovery capsule

0x35h X X O O X O X O

Handing off control to the crisis recovery capsule

0x3Fh X X O O O O O O Crisis recovery capsule failed integrity check of capsule descriptors

Runtime Phase / EFI Operating System Boot

0XF2h O O O O X X O X Signal that the OS has switched to virtual memory mode

0XF4h O O O O X O X X Entering the sleep state

0XF5h O O O O X O X O Exiting the sleep state

0XF8h O O O O O X X X

Operating system has requested EFI to close boot services has been

cancelled.

Progress Code

0XF9h O X X O X X X X Resetting the keyboard

0xFAh O X X O X X X O Disabling the keyboard
