iii

Board Identification Information

Basic Desktop Board DH77EB Identification Information

AA Revision

BIOS Revision

Notes

G39073-303

EBH7710H.86A.0041

1,2

G39073-304

EBH7710H.86A.0053

1,2

G39073-400

EBH7710H.86A.0053

1,2

Notes:

1. The AA number is found on a small label on the component side of the board.

2. The H77 chipset used on this AA revision consists of the following component:

Device

Stepping

S-Spec Numbers

Intel H77 Express Chipset C1 SLJ88

Specification Changes or Clarifications

The table below indicates the Specification Changes or Specification Clarifications that

apply to the Intel

Desktop Board DH77EB.

Specification Changes or Clarifications

Date Type of Change Description of Change or Clarification

October 2012 Spec Clarification

Updated Table 39. Environmental Specifications to address

operating temperature requirements for the board.

May 2013 Spec Clarification

Added ENERGY STAR Note to Section 5.1.6.

July 2013 Spec Clarification

Deleted references to ENERGY STAR.

Errata

Current characterized errata, if any, are documented in a separate Specification

Update. See

http://www.intel.com/content/www/us/en/motherboards/desktop-

motherboards/motherboards.html?wapkw=desktop+boards for the latest

documentation.
