Configuration

Order Code

Form Factor

Drive Bays

Optical Bay

System Cooling

Power Supply

Add-in card support

Dimensions (H x W x D)

Front Panel Features

(optional front panels available)

Components Included

Fixed

SR1600UR

1U Rack

Three Fixed 3.5” SATA HDDs

One slim SATA optical drive bay

5 Non redundant dual-rotor fans

600-watt high efficiency fixed

1 full-height (PCI Express 2.0 x16)

1 Intel® I/O Expansion Module

(PCI Express 2.0 x8)

1.7” ( 43.3mm) x 16.9” (430mm)

x 27.19” (690.6mm)

Power LED

Hard Drive Activity LED

System status LED

2 NIC LEDs

System ID LED

Power/sleep switch

Reset switch

NMI switch

Bootable USB 1.1 port

Intel® Server Board S5520UR

Cabled front panel

Intel® Server Chassis SR1600

3 fixed HDD sleds

600-Watt Power Supply

5 fans

One full height PCI Express*

2.0 x16 riser

ODD tray

Fan Board

Pre-routed cables

Memory blanks

2 CPU Heatsinks

SAS

SR1600URHS

1U Rack

Three Hot Swap 3.5” SAS/SATA HDDs

One slim SATA optical drive bay

5 Non redundant dual-rotor fans

600-watt high efficiency fixed

1 full-height (PCI Express 2.0 x16)

1 Intel® I/O Expansion Module

(PCI Express 2.0 x8)

1.7” ( 43.3mm) x 16.9” (430mm)

x 27.19” (690.6mm)

Power LED

Hard Drive Activity LED

System status LED

Power/sleep switch

2 NIC LEDs

Reset switch

NMI switch

System ID LED

VGA port

Bootable USB 1.1 port

Intel® Server Board S5520UR

Standard front panel

Intel® Server Chassis SR1600

3 hot swap HDD carriers

600-Watt Power Supply

5 fans

One full height PCI Express*

2.0 x16 riser

ODD tray

Pre-routed cables

Memory blanks

2 CPU Heatsinks

* requires BackPlane

SATA

SR1625UR

1U Rack

Up to eight Hot Swap 2.5” SATA HDDs

One slim SATA optical drive bay

5 Non redundant dual-rotor fans

650-watt 1+0 high efficiency, hot swap,

redundant capable

1 full-height (PCI Express 2.0 x16)

1 Intel® I/O Expansion Module

(PCI Express 2.0 x8)

1.7” ( 43.3mm) x 16.9” (430mm)

x 27.19” (690.6mm)

Power LED

System status LED

System ID LED

Power/sleep switch

NMI switch

System ID switch

Bootable USB 1.1 connection

Intel® Server Board S5520UR

Mini front panel

Intel® Server Chassis SR1625

6 hot swap HDD carriers

One 650 Watt Power Supply

5 fans

One full height PCI Express*

2.0 x16 riser

ODD tray

Pre-routed cables

Passive midplane

Memory blanks

2 CPU Heatsinks

SAS

SR1625URSAS

1U Rack

Up to eight Hot Swap 2.5”

SAS/SATA HDDs

One slim SATA optical drive bay

5 Non redundant dual-rotor fans

650-watt 1+0 high efficiency, hot

swap, redundant capable

1 full-height (PCI Express 2.0 x16)

1 Intel® I/O Expansion Module

(PCI Express 2.0 x8)

1.7” ( 43.3mm) x 16.9” (430mm)

x 27.19” (690.6mm)

Power LED

System status LED

System ID LED

Power/sleep switch

NMI switch

System ID switch

Bootable USB 1.1 connection

Intel® Server Board S5520UR

Mini front panel

Intel® Server Chassis SR1625

6 hot swap HDD carriers

One 650 Watt Power Supply

5 fans

One full height PCI Express*

2.0 x16 riser

ODD tray

Pre-routed cables

Active SAS midplane

(with optional HW RAID support)

Memory blanks

2 CPU Heatsinks

Intel® Server Systems SR1600UR, SR1625UR Specifications
