10

2. Spares and Accessories Order Codes

2.1 I/O Modules


Product Code

MM

UPC

Description

Minimum

Order

Quantity

AXX10GBIOMOD

Avail. Post SRA.

10GbE I/O module Dual port CX4 connector.

1

AXX4GBIOMOD2

901359

735858206532

Quad port GbE I/O module. RJ-45

connectors.

1

AXXIBQDRMOD

Avail. Post SRA.

Single port QDR speed InfiniBand I/O

Module. CX4 powered connector.

1

AXX4SASMOD

900946

00735858206372

Internal 4-port SAS module, based on LSI

1064e controller, with Em bedded RAID

support. (primarily targeted at non-intel

chassis)

1

AXXROMBSASMR

901641

735858208017

Internal 4-port SAS module, based on LSI

1078e controller. Provides 4 port full featured

SAS/SATA RAID 0,1,5, 6 and striping

capability for spans 10, 50, 60. (primarily

targeted at non-intel chassis)

1

AXXIBIOMOD

881891

735858185219

InfiniBand I/O Expansion Module, SDR

speed. Compatible with Intel Server Boards

S5000PALR and S5520UR.

1
