Electrical Specifications

Table 2. Voltage Identification Definition

VID5 VID4 VID3 VID2 VID1 VID0 VID VID5 VID4 VID3 VID2 VID1 VID0 VID

0 0 1 0 1 0 0.8375 0 1 1 0 1 0 1.2125

1 0 1 0 0 1 0.8500 1 1 1 0 0 1 1.2250

0 0 1 0 0 1 0.8625 0 1 1 0 0 1 1.2375

1 0 1 0 0 0 0.8750 1 1 1 0 0 0 1.2500

0 0 1 0 0 0 0.8875 0 1 1 0 0 0 1.2625

1 0 0 1 1 1 0.9000 1 1 0 1 1 1 1.2750

0 0 0 1 1 1 0.9125 0 1 0 1 1 1 1.2875

1 0 0 1 1 0 0.9250 1 1 0 1 1 0 1.3000

0 0 0 1 1 0 0.9375 0 1 0 1 1 0 1.3125

1 0 0 1 0 1 0.9500 1 1 0 1 0 1 1.3250

0 0 0 1 0 1 0.9625 0 1 0 1 0 1 1.3375

1 0 0 1 0 0 0.9750 1 1 0 1 0 0 1.3500

0 0 0 1 0 0 0.9875 0 1 0 1 0 0 1.3625

1 0 0 0 1 1 1.0000 1 1 0 0 1 1 1.3750

0 0 0 0 1 1 1.0125 0 1 0 0 1 1 1.3875

1 0 0 0 1 0 1.0250 1 1 0 0 1 0 1.4000

0 0 0 0 1 0 1.0375 0 1 0 0 1 0 1.4125

1 0 0 0 0 1 1.0500 1 1 0 0 0 1 1.4250

0 0 0 0 0 1 1.0625 0 1 0 0 0 1 1.4375

1 0 0 0 0 0 1.0750 1 1 0 0 0 0 1.4500

0 0 0 0 0 0 1.0875 0 1 0 0 0 0 1.4625

1 1 1 1 1 1 VR output off 1 0 1 1 1 1 1.4750

0 1 1 1 1 1 VR output off 0 0 1 1 1 1 1.4875

1 1 1 1 1 0 1.1000 1 0 1 1 1 0 1.5000

0 1 1 1 1 0 1.1125 0 0 1 1 1 0 1.5125

1 1 1 1 0 1 1.1250 1 0 1 1 0 1 1.5250

0 1 1 1 0 1 1.1375 0 0 1 1 0 1 1.5375

1 1 1 1 0 0 1.1500 1 0 1 1 0 0 1.5500

0 1 1 1 0 0 1.1625 0 0 1 1 0 0 1.5625

1 1 1 0 1 1 1.1750 1 0 1 0 1 1 1.5750

0 1 1 0 1 1 1.1875 0 0 1 0 1 1 1.5875

1 1 1 0 1 0 1.2000 1 0 1 0 1 0 1.6000
