Electrical Specifications

Datasheet 41

Figure 7. Deeper Sleep V

and I

Loadline

10 mV = Ripple for

PSI# Asserted

Slope = -5.7 mV/A at package

VCC_SENSE, VSS_SENSE pins.

Differential Remote Sense required.

CC_CORE

(V)

CC_CORE

(A)

CC_CORE, DC

Min

(Deeper Sleep)

CC_CORE

Min

(Deeper Sleep)

±V

CC_CORE

Tolerance

= VR ST Pt Error 1/

CC_CORE

Nom

(Deeper Sleep)

CC_CORE

Max

(Deeper Sleep)

CC_CORE, DC

Max

(Deeper Sleep)

CC_CORE

Max

(Deeper Sleep)

Note 1/ Deeper Sleep VCC_CORE Set Point Error Tolerance is per below:

Tolerance – PSI# Ripple

--------------------------------

± [(VID*1.5%) – 3 mV]

± (11.5 mV) – 3 mV]

± (25 mV) – 3 mV]

CC_CORE

VID Voltage Range

----------------------------------------

CC_CORE

> 0.7500 V

0.7500 V ≤ V

CC_CORE

≤ 0.5000 V

0.5000 V < V

CC_CORE

≤ 0.4125 V
