Product Description

1.11.2 Thermal Monitoring

Figure 12 shows the location of the sensors and fan connectors for the D915PBL board.

OM17055

EFGH

Item Description

Thermal diode, located on processor die

Remote ambient temperature sensor

Ambient temperature sensor, internal to hardware monitoring and fan control

ASIC

Processor fan

Rear chassis fan 1

Front chassis fan

ATX fan (optional)

Rear chassis fan 2

Figure 12. Thermal Monitoring for D915PBL Board
