Byte 0 Byte 0

Word 0 [31:24] Word 0 [23:16] Word 0 [15:8] Word 0 [7:0]

Word 0 [7:0] Word 0 [15:8] Word 0 [23:16] Word 0 [31:24]

32-Bit Word on Internal Data Bus

32-Bit Word on PCI Bus

+3 +2 +1 +0

B6189

+7 +6 +5 +4 +3 +2 +1 +0

Byte A Byte B Byte C Byte D

Word 1 [7:0] Word 1 [15:8] Word 1 [16:23] Word 1 [31:24]

Two 32

Bit Words on

Internal Data Bus

Two 32

Bit Words

on 64-Bit PCI Bus

Word 0 [31:24] Word 0 [23:16] Word 0 [15:8] Word 0 [7:0]

Word 0 [7:0] Word 0 [15:8] Word 0 [23:16] Word 0 [31:24]

Byte A Byte B Byte C Byte D Word 1 [31:24] Word 1 [23:16] Word 1 [15:8] Word 1 [7:0]

B6190

1 2 ... 73 74 75 76 77 78 79 80 81 82 83 ... 823 824
